Doorlock
DOORLOCK RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
GLASSHATCH\_CF – translation sunroof glass
LONG\_PRESS\_TM\_CF – translation duration of pressing
CRASH\_DETECTION\_CF – accident detection. Activation of an alarm by the ABS unit during sudden braking.
PLANT\_LOCK\_WITH\_SPEED\_CF – Automatic closing of central lock. The doors can be closed automatically after the vehicle starts moving.
AUTO\_RELOCK\_TIMEOUT\_CF (min) – Change the timeout for automatic re-closing of the central lock By default, if you opened the central lock with a key, but after that did not open any of the doors within 2 minutes, then CEBKS will close the central lock again automatically. Change the value to the desired one in minutes, or disable it altogether by setting the value to 0.
ANTI\_HIJACK\_CF – Anti-theft mode. When the button is pressed, opening with free hands is partially disabled. It closes itself, and to open it you need to press the button on the map. The first press opens the driver’s door, the second opens all the others. When activated, opening with free hands is disabled. It closes itself and to open it you need to press the button on the map.
BTN\_TAILGATE\_OPENING\_CF – maybe in some configurations there is a trunk opening button in the cabin
RKE\_BTN\_TAILGATE\_OPENING\_CF – When you press a button on the key card, if the car was closed, the trunk lid opens and you can simply raise it without pressing the button on the trunk itself.
SEPARATED\_TAILGATE\_OPENING\_CF – separate opening of the trunk lid. Opening the trunk without opening the central lock.
KNOB\_CF –when you press the close button, do not close
HIGH\_LOCK\_WITH\_SPEED\_CF – Enables the door locking from the outside when the speed is 7 km / h, and if you stop at a traffic light, then no one will get in to you from the outside until you open it from the inside with a handle, a button on the panel or map.
SUPERLOCK\_CF – When the closing button is pressed twice, it locks the rear doors from the inside, i.e. passengers will not get out on their own, or if thieves break the glass, the doors will not be opened with an internal handle either
CHILD\_LOCK\_CF – activates a button on the driver’s door to lock the rear doors and windows from the inside. Children in the back will not be able to open doors and windows.
GLASSHATCH\_CF – translation of sunroof glass
HANDS\_FREE\_CF – If the parameter is off, then when the car starts, it will ask to insert a “Free hands” card into the corresponding slot
RKE\_BACK\_DOORS\_CF –
FUEL WAC LOCKING DELAY TM CF (min) – Sets the specified delay interval for blocking the fuel tank flap.
CAR\_BODY\_TYPE\_E\_CF – translation of the car body type
POWER\_SLIDING\_DOORS\_CF – translation of sliding doors
CHILD\_LOCK\_SWITCH\_REVERSE\_CF – Reversible operation of the CHILD\_LOCK\_CF mode
BATT\_TAILGATE\_OPENING\_CF – translation of opening the trunk lid
External lights
External lights RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
DUAL\_BULBS\_CF – Double bulbs. When activated, the dipped beam will not turn off when the main beam is turned on. If not activated when switching to the far one, the near one goes out, and the far one lights up. When you turn off the far one, the near one turns on again.
VEHICLE\_RECOGNITION\_TP –
LIGHT\_SENSOR\_FITTED\_AND\_USED\_CF – installation and use of the light sensor
DRL\_ACTIVE\_CF – activation of DRL
SHIFT\_UP\_HEADLAMPS\_CF – Reminder to the driver that the manual transmission can be shifted to a higher gear, of course, to save fuel. It turns on when acceleration has stopped in the current gear and it is pointless to thresh with engine speed further.
RR\_FOG\_LAMP\_CF – rear PTF.
AHL\_CONFIG\_BY\_USER\_CF – In some, the configuration includes the System Visio function, which is designed to monitor lanes and warn about crossing the line in time and also to automatically switch from far to near and vice versa. For full activation, you still need to activate two items in the tidy: Presence AHL and Presence LDW.
BATTERY\_SAVE\_CF – Battery saving. check. something has to do with the mode of saving the battery charge, or this is when the car is not closed for 15 minutes, the radio tape recorder and everything else works, or when closed, the left light goes out.
FR\_FOG\_LAMP\_CF – front PTF.
AUTO\_LIGHT\_CF – Auto light, with a light sensor.
SWISS\_CF – Swiss light, check what is this, the same as Canadian? when you turn on the handbrake and N the near turns off or PTF instead of the near? check
SCANDINAVIAN\_RUNNING\_LIGHT\_CF- Auto on and off low beam and dimensions with the establishment of a car.
FOLLOW\_ME\_HOME\_CF – turning on the dipped headlights for 30-120 seconds after closing the car – after stopping the internal combustion engine, pull the dimmer towards you (including the far one), adjust the glow time by moving the lever towards you 30-60-120.
REMOTE\_LIGHTING\_CF – remote control of lighting, when you press the key fob button, the light turns on for a while.
LIGHT\_SENSOR\_CF – Light sensor sensitivity SOUTH / NORTH
AUTO\_LIGHT\_SENSITIVITY\_CF – Light sensor sensitivity HIGH / LOW
Flasher
FLASHER lights RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
HAZARD\_WITH\_BRAKE\_CF – warning during heavy braking
HAZARD\_WITH\_CRASH\_CF – warning in case of an accident
OVERLOAD\_BY\_SMART\_CF –
TPULSE\_CF – Polite (impulse) turn signals – short (without fixation) movement of the turn signal lever – triple blinking of lamps.
PC\_SIGNALISATION\_CF
Front wiper
FRONT WIPER lights RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
FRONT\_WIPER\_CF – The presence of the front brushes
AUTO\_WIPE\_CF – The automatic mode of the brushes (most likely the presence of a rain sensor)
FRONT\_DROP\_WIPE\_CF – Additional wiping down after washing. The wiper makes 3 passes. After the 3rd pass and a delay of 3 seconds, another final brush pass is performed.
SWITCH\_HI2LO\_LO2INT\_CF – When the machine stops, the brushes change speed from fast to slow
HEADLAMP\_WASHER\_CF – Headlamp washer is present.
DUAL\_WIPING\_MOTOR\_CF – translation: double wiper motor.
GO\_TO\_SERVICE\_POSITION\_TM\_TP (ms) – Time to switch to service mode (when the switch is turned off to the stop, pull the brushes vertically up to the stop)
SES Function
SES functions RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
CF\_VSC\_WAC\_Buzzer\_inhibited – After automatic closing of the car with a smart key, the central locking system will lock everything, and there will be a sound signal. sans (without), avec ©
CF\_VSC\_HandFreeLockByDoorHandle – Opening doors when the hand is brought to the touch sensor in the door.
CF\_VSC\_WAC – Central lock is blocked when you leave the car, if you have a smart card
CF\_VSC\_HandFreeUnLock – Activation of the hands-free function.
VSC\_Timeout\_Learning\_Key – translation: learning timeout key
IMMO\_Timeout\_REWORK\_MODE\_TM\_CF (min) – translation: Immo waiting mode for TM MB
alteration VSC\_WARNING\_BATTERY\_LEVEL\_IDENTIFIER – Notification on the dashboard about a dead battery in the key card.
CF\_VSC\_WAC\_NB\_RF\_FRAME\_LOST (time) – translation: Servant card function authorization
LockUnlockByButtonCF – Unlock lock using the BF button. Use on door handle optical sensor to unlock Use on door handle optical sensor to unlock
CF\_VSC\_AVEC\_DEMARRAGE\_ML – CF VSC WITH START ML. Actif is active. Inactif inactive
CF\_VSC\_WAC\_BACKUP
CF\_VSC\_SANS\_Locking\_des\_Badges – No icon lock.
CF\_VSC\_Driver\_Right – steering wheel location? conduite a droite right-hand traffic, conduite a gauche – left hand drive
CF\_VSC\_CAR\_BODY\_AND\_THATCHAM – BODY AND THATCH
CF\_VSC\_WITH\_SERVANT\_IDENTIFER – WITH SERVICE ID
Window Control
WINDOW control functions RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
AUTO\_WINDOW\_CLOSING\_CF – Automatic closing of all windows when you double-click on the key fob button, only impulse windows work.
LVE\_CF – Operation of the rear power windows
FRONT\_PASSENGER\_WLAP\_ECU\_CF –
REAR\_PASSENGER\_WLAP\_ECU\_CF –
CF\_VSC\_WAC\_NB\_CHECK\_LOOP (time)
Perimetric Alarm
Perimetric Alarm control functions RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
Perimetric\_alarm\_CF – SETTING ON the alarm
GLASSHATCH\_CF –
External Lights
External lights control functions RENAULT FLUENCE MEGANE CLIO ARKANA KOLEOS DUSTER DDT4ALL FUNCTIONS
DUAL\_BULBS\_CF – Dual bulbs presented
DRL\_ACTIVE\_VF – USING the DRL for the daily light
AUTO\_LIGHT\_VF – If is presented the sensor
SCANDINAVIAN\_RUNNING\_LIGHT – ALL THE TIME the lights are on
FOLLOW\_ME\_HOME\_CF – FOLLOW AND WELCOME home lights
LIGHT\_SENSOR\_CF – Position of sensor light
AUTO\_LIGHT\_SENSITIVITY\_TP – CHANGE the sensitivity of the light sensor
